Features
VOLTAGE RANGE 50 to 1000 Volts
CURRENT 1.0 Ampere
Low forward voltage drop
Low leakage current
High forward surge capability
High temperature soldering guaranteed
260℃/10 seconds,0.375”(9.5mm)lead length at 5 lbs(2.3kg) tension
Detailed Specifications
MECHANICAL DATA
Case: Transfer molded plastic
Epoxy: UL94V-0 rate flame retardant
Polarity: Color band denotes cathode end
Lead: Plated axial lead, solderable per MIL-STD-202E method 208C
Mounting position: Any
Weight: 0.012ounce, 0.33 grams
Main Applications
Industrial：Motor Control,Smart Power Meter,Welder,Industrial Air Conditioning
Automotive：Electric Vehicle Charging Station, DC Converter, Switching, Inverter, Control/Monitor
Computing：Input Stage Rectification, Transient Protection, ESD Protection, DC/DC Power, Camera Motor Drive
Aerospace：Cockpit Electronics, Engine Systems, Actuation Systems, Communications, Passenger Cabin Systems
Medical：Hearing Aid, Glucometer, Electrocardiograph, Patient Monitor, Supervisory, Ultrasound Imaging
LED Lighting：LED Street Lamp, Compact Fluorescent Lamp (CFL) , Rice cooker, Garden Lighting, LCD, Backlighting
Consumer：SMPS, Uninterruptable Power Supply, ORing Diode Function, Application_Low Voltage Power
Power Supply：SMPS, Uninterruptable Power Supply, ORing Diode Function, Application_Low Voltage Power
Alternative Energy：Power Bank, Smartphone, Tablet, Wearable, Wireless Headset, Solar Panel, Solar Inverter
