WEET WFCA THB 85 ℃ 85% X2 Metallized Polypropylene Film Capacitor 275V 305V 310VAC

Features

OPERATING TEMPERATURE ：-40℃ to +110℃ for which the capacitor can be operated continuously at rated voltage.
Non-inductive, (UL940V-0) plastic case sealed with epoxy resin. Gray Plastic Shell and Gray Epoxy
Across-the-line EMI filtering and connection in series with the mains for high stability grade applications
For capacitive divider power supply. Such as power meter, smart meters, LED driver, and other sever ambient condition
Metallized Polypropylene Film Capacitor, Aluminum Metallized Polypropylene Film Capacitors (On request)
In accordance with VDE, ENEC and UL safety regulation class X2

Detailed Specifications

Operating Temperature	-40℃~ +110℃
Voltage Rating	275V, 305V, 310VAC
Capacitance Range	0.0047 ~ 10.0μF
Capacitance Tolerance	±10% (K) standard
Package	Bulk, Ammo Tape Package
Insulation Resistance	CR≤0.33 μF, I.R≥15,000MΩ CR>0.33 μF, I.R≥5,000S （20℃，100V,1min）
	0.0010μF≤CR≤0.47μF ≤0.1% (1KHz,20℃)
Dissipation Factor	0.47μF≤CR≤1.0μF ≤0.2% (1KHz,20℃)
	1.0μF≤CR≤10μF≤0.3% (1KHz,20℃)
Voltage Proof	4.3UR DC /5s
High Temperature High humidity	Test Temperature: +85 ± 2℃. Test Humidity: 85% ± 2% R.H. Test Voltage: 240VAC Test Duration: 500 Hrs. Capacitance change rate ≤10% After test, allow it stay alone for 1.5 ± 0.5 Hrs. at ordinary condition before making measurements.
